1st Gen
Key reference: 10961827
Select variant
Select variant
Diagnostic port location (OBD)
Illustrative — for orientation only.
RHD (UK): Driver's footwell on the outboard (door) side, to the RIGHT of the steering column, tucked up behind the lower edge of the dash just under the bonnet release handle and roughly where your right knee sits. Crouch at the open driver's door and look up above the accelerator: the 16-pin socket is clipped into a frame in the lower dash trim, facing down. It is not left of the column and not in the centre console. If it is not in its frame it has usually popped out of its clips and is hanging loose behind the trim nearer the column. LHD: mirrored, to the left of the steering column above the footrest, at the top left of the pedal box. Same position on all first-generation ZS trims (Explore, Excite, Exclusive) and on the ZS EV, which shares the dash.
