B9 (Partner van and Partner Tepee) - phase 1 2008-2012, facelift 2012, facelift 2015-2018; same van as the Citroen Berlingo II B9
Key reference: 6490C7
Verified · record updated 16 Oct 2026
Key variant · 1 of 5
Key
Compatible tools
ConfirmedOBD port
Illustration — use it to know where to look.
Low under the steering column, behind the plastic trim below the wheel, next to the fascia fuse box; on most vans the green 16-pin socket sits towards the right of that opening. Same on panel van, crew van and Partner Tepee, and unchanged through the 2012 and 2015 facelifts.
Open the fuse box flap and unclip the plastic cover under the steering column by hand (flat blade if tight); the socket is exposed behind it. The socket can be a tight fit - push the plug in firmly.
