YB (1st generation, pre-facelift; YB CUV, Rio YB platform)
Key reference: 95430-H8600
Checked against tool makers' lists and key suppliers. We only change this date when the data has been rechecked against evidence, not for small edits. Spot something wrong? Use Report a data issue at the bottom of this page and we'll look again.
Key variant · 1 of 2
Key
Compatible tools
ConfirmedOBD port
Illustration — use it to know where to look.
Driver's side, under the lower dash panel, directly below the inner fuse panel. The 16-pin socket is mounted under the panel and faces down, so it is easy to miss: crouch at the open driver's door with a torch and look up. Same position on all trims. LHD: left of the steering column, below (not inside) the fuse panel, above the clutch pedal. RHD (UK): driver's side under the lower dash panel below the inner fuse panel, above the pedals.
