ZE2 (2nd generation)
Key reference: 35118-TM8-E00
Select variant
Select variant
Diagnostic port location (OBD)
Illustrative — for orientation only.
RHD (UK, Ireland): driver's footwell, on the INBOARD side — left of the steering column, tucked up under the lower edge of the dash between the column shroud and the centre console, above the accelerator. It is a short reach up and left from the driver's seat; the under-dash fuse box with its clip-off cover sits on the outboard side of the same footwell, so if you are looking at the fuse lid you have gone the wrong way round the column. LHD (continental Europe): same central under-dash position but on the inboard side of the column, i.e. to the right of the steering column above the accelerator. Position is identical on every grade — S, SE, ES, ES-T, EX and the 2012-facelift HE/HS/HX all share it, and the 2012 facelift did not move it.
