Honda CR-V
2007–2011

Illustration — use it to know where to look.

Location

Under the driver's side of the dash, to the RIGHT of the steering column (inboard side), mounted in the bottom edge of the lower dash panel directly above the accelerator pedal and short of the centre console. The 16-pin connector faces the floor, so you will not see it from the seat - put your head down into the footwell and look up past the column over the gas pedal. Every US 2007-2011 CR-V is left-hand drive and the position is the same on LX, EX, EX-L and the 2011 SE, 2WD and 4WD, either side of the 2010 facelift. Pin 7 (K-line) is the line the immobiliser unit talks on, so a lead that only wires the CAN pins will scan the engine but not reach the immobiliser.
