G30 / G31 (incl. F90 M5)
Key reference: 66128717503
Select variant
Select variant
Diagnostic port location (OBD)
Illustrative — for orientation only.
RHD (UK): driver's footwell, on the door side of the steering column, tucked high under the lower edge of the dash and set forward — sight up from the driver's seat and the 16-pin socket faces down at you from directly above the accelerator pedal. It is far enough back that most people feel for it before they see it. LHD: the mirrored position, left of the steering column above the footrest. Same place on every G30 saloon, G31 Touring and F90 M5, SE through M Sport, and unchanged by the 2020 facelift. The socket is exposed and points downward — there is no lid, flap or trim to unclip before plugging in.
