Chevrolet Silverado 2500HD / 3500HD OBD port location

One generation, 2015–2019.

2015–2019

GMT K2XX

Illustration — use it to know where to look.

Location

Left-hand drive (US trucks): under the driver's side of the dashboard, below the left side of the dash near the steering column. The port faces outwards towards the driver. The 2015 2500HD service manual places the DLC below the left side of the dash, and a 2018 2500HD/3500HD wiring guide puts it under the driver dash, so the position is the same across this generation. Only the left-hand-drive position is evidenced; this truck was not sold in right-hand drive in this market. If the tool won't talk, check the 12V power outlet fuse first: the port shares that circuit on Silverados.

Also on this Silverado 2500HD / 3500HD

  • KeysTransponder
  • Tools confirmed2
  • Transponder chipSubscribers
  • Programming procedureSubscribers
Open the full Silverado 2500HD / 3500HD GMT K2XX record

Questions

Chevrolet Silverado 2500HD / 3500HD OBD questions

GMT K2XX (2015–2019): Left-hand drive (US trucks): under the driver's side of the dashboard, below the left side of the dash near the steering column.
