296 (X82, Trafic III based)
Key reference: 805647402R
Checked against tool makers' lists and key suppliers. We only change this date when the data has been rechecked against evidence, not for small edits. Spot something wrong? Use Report a data issue at the bottom of this page and we'll look again.
Key variant · 1 of 2
Key
Compatible tools
ConfirmedOBD port
Illustration — use it to know where to look.
LHD: in the driver's side lower dashboard, below and to the left of the steering column, inside the passenger compartment fuse box area behind the lower storage compartment. The connector sits with the cabin fuses, so it is out of sight until the compartment is removed. No trim difference found. RHD: not covered by this market record (the twin vans move the cabin fuse box to the other side on RHD) — check behind the driver's lower dash panel first.
Unclip the lower storage compartment (the fuse box cover) by squeezing it on both sides and pulling it towards you. No tools needed. The fuse puller is clipped to the back of the flap. The OBD connector is then visible in the fuse box area.
