Toyota Hilux Revo OBD port location
One generation, 2015–2023.
2015–2023
AN120/AN130
Illustration — use it to know where to look.
Location
(Middle East, Latin America, LHD Europe/Africa): under the steering column on the lower edge of the driver's knee panel, directly above the brake pedal. The 16-pin socket faces down and is visible from the driver's seat once you look under the column - no cover. Same position on single, extra and double cab and on the 2020 facelift.
